A strong 23hp Kohler® Vtwin engine delivers reliable power to tackle your yard.
46-in. heavy-duty fabricated Airforce™ deck cutting system that has been tested and proven to deliver a best-in-class cut, meaning fewer clumps and stragglers, finer clippings and increased evenness.
AGM battery delivers reliable starting with slower discharge, so you worry less about your battery going dead in the offseason.
Tuff Torq Hydrostatic transmission, no shifting, just push the pedal and go.
Engine
Engine Brand Kohler®
Engine Model FR Series
Engine Model Number 651V
Engine Displacement 726cc
Engine Output 21.5HP
Starter Type Electric
Fuel Tank Capacity 3 gal. US (11.35 L)
Cylinders Twin
Engine Start Ignition Key
Engine Oil Capacity 2.1 qt. US ( 2 L)
Lubrication Fully pressurized
Charging System 15 amp regulated
Fuel Gauge No
Governor Mechanical
Choke Separate Choke
Air Filter Single element
Oil Filter Yes
Fuel Delivery Carburetor
Battery
Battery 300 CCA
Battery Type AGM (Absorbent Glass Mat)
Battery Voltage 12V
Drive System
Transmission Tuff Torq® K46
Forward Speed 5.5 MPH / 8.6 KMH
Reverse Speed 3 MPH / 4.8 KMH
Rear Axle 1"
Drive System Hydrostatic
Transmission Housing Aluminum
Engine to Transmission Heavy-duty belt
Rear Differential Lock No
Controls
Cruise Control Yes
Brakes Disc
Cutting Deck
Deck Cutting Width 46 in
Deck Wash Yes
Deck Material 11-gauge steel
Deck Engagement (PTO) Electric
Deck Construction Fabricated
Blade(s) Two
Deck Lift Hand lever with spring-assist
Cutting Height Range 1" - 4"
Anti-Scalping Four gauge wheels
Deck Positions 12
Comfort
Seat Type 15" Cut-n-Sew high-back
Armrests Yes
Seat Adjustment Lever
Floor Mats Rubber
Additional Specifications
Mulch Kit Available Separately
Headlight(s) Dual-LED
Cup Holder Yes
Operator Presence System Yes
Model Number 13AFA1TNA10
Warranty
Warranty 3-year unlimited hours
Frame Warranty 5-year unlimited hours
Front Axle Warranty 5-year unlimited hours
Deck Shell Warranty Lifetime limited
Commercial Warranty No
Chassis
Frame Robotically welded
Turning Radius 16"
Bumper Steel tube
Rear Tow Hitch Yes
Corrosion Protection Yes
Front Pivot Bar Cast iron
Wheels
Bearing Type Ball Bearing
Rear Tires 20"x 8"-8"
Front Tires 15"x 6"-6"
Tire Tread Multi Trac
Disclaimer
Specifications Disclaimer Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website
